GRAPHTEC midi LOGGER GL800 User Manual page 23

Checks and Preparation
Wiring
Cable tips are bare tips. Perform wiring for the necessary functions.
Logic/Pulse output
Alarm output
Trigger input
GND
*Switch between logic and pulse.
2-8
Signal Name Channel Number
1
2
3
4
1
2
3
4
Wire Color
Orange with red dotted line
Orange with black dotted line
Grey with red dotted line
Grey with black dotted line
White with red dotted line
White with black dotted line
Yellow with red dotted line
Yellow with black dotted line
Pink with red dotted line
Pink with black dotted line
Shielded
Orange with red dotted line
Orange with black dotted line : 2
Grey with red dotted line
Grey with black dotted line
White with red dotted line
White with black dotted line
Yellow with red dotted line
Yellow with black dotted line
Pink with red dotted line
Pink with black dotted line
Shielded
: 1
Logic/Pulse input
: 3
: 4
: 1
: 2
Alarm output
: 3
: 4
: Trigger input
GND
