Checks and Preparation

LAN Connection

Use a LAN cable to connect the GL800 to a PC.
LAN cable
Cable Types
• Use a crossing cable when connecting directly to a PC, without using a hub.
LAN cable
(crossing)
• Use a straight cable when using a hub.
LAN cable
HUB
LAN cable
(straight)
(straight)
2-11
