1.1 Purpose of the Manual

The frequency converter is designed to provide high shaft
performance on electrical motors. Read these operating
instructions carefully for proper use. Incorrect handling of
the frequency converter may cause improper operation of
the frequency converter or related equipment, shorten
lifetime, or cause other troubles.
These operating instructions provide information on:
•
Start-up.
•
Installation.
•
Programming.
•
Troubleshooting.
•
Chapter 1 Introduction introduces the manual and
informs about approvals, symbols, and abbrevi-
ations used in this manual.
•
Chapter 2 Safety Instructions entails instructions on
how to handle the frequency converter in a safe
way.
•
Chapter 3 How to Install guides through the
mechanical and electrical installations.
•
Chapter 4 How to Programme explains how to
operate and programme the frequency converter
via the LCP.
•
Chapter 5 General Specifications contains technical
data about the frequency converter.
•
Chapter 6 Warnings and Alarms assists in solving
problems that may occur when using the
frequency converter.
®
VLT is a registered trademark.
DeviceNet™ is a trademark of ODVA, Inc.

1.2 Additional Resources

•
The VLT
Guide details all technical information about the
frequency converter and customer design and
applications.
•
The VLT
Programming Guide provides information on how
to programme and includes complete parameter
descriptions.
•
The VLT
provides information about installing and trouble-
shooting of the PROFIBUS fieldbus option.
•
The VLT
Guide provides the information required for
4
VLT
®
AutomationDrive FC 301/FC 302 Design
®
AutomationDrive FC 301/FC 302
®
PROFIBUS DP MCA 101 Installation Guide
®
PROFIBUS DP MCA 101 Programming
Danfoss A/S © 04/2016 All rights reserved.
®
AutomationDrive FC 302
controlling, monitoring, and programming the
frequency converter via a PROFIBUS fieldbus.
•
The VLT
provides information about installing and trouble-
shooting of the DeviceNet
•
The VLT
provides the information required for controlling,
monitoring, and programming the frequency
converter via a DeviceNet
Danfoss technical documentation is also available online at
http://drives.danfoss.com/knowledge-center/technical-
documentation/.

1.3 Document and Software Version

This manual is regularly reviewed and updated. All
suggestions for improvement are welcome. Table 1.1 shows
the document version and the corresponding software
version.
Edition
MG34Q4xx F14 and F15 enclosure sizes added.
Table 1.1 Document and Software Version

1.4 Approvals and Certifications

1.4.1 Approvals
The frequency converter complies with UL 508C thermal
memory retention requirements. For more information,
refer to the section Motor Thermal Protection in the
product-specific design guide.
NOTICE
Imposed limitations on the output frequency
(due to export control regulations):
From software version 6.72 onwards, the output
frequency of the frequency converter is limited to
590 Hz. Software versions 6.xx also limit the maximum
output frequency to 590 Hz, but these versions cannot
be flashed, that is, neither downgraded nor upgraded.
®
DeviceNet MCA 104 Installation Guide
®
fieldbus option.
®
DeviceNet MCA 104 Programming Guide
®
fieldbus.
Remarks
Software version update.
Software
version
7.4x
MG34Q402
