How to Install
See chapter 5.1 Mains Supply for the correct dimensioning of the motor cable cross-section and length.
NOTICE
Only use the cross-section the field wiring terminals are
designed for. The terminals do not accept a wire of 1 size
large.
R1
S1
T1
R2
S2
T2
A
R1
S1
T1
R2
S2
T2
B
Illustration 3.33 A) Temporary 6-Pulse Connection
B) 12-Pulse Connection
Notes
1) When 1 of the rectifier modules is inoperable, use the operable rectifier module to run the frequency converter at a
reduced power. Contact Danfoss for reconnection details.
MG34Q402
Operating Instructions
91-1
Recti er 1
92-1
93-1
91-2
Recti er 2
92-2
93-2
95
91-1
Recti er 1
92-1
93-1
91-2
Recti er 2
92-2
93-2
95
1)
