How to Install

3.2.4.3 Inverter, Enclosure Sizes F12 and F13

3 3
FASTENER TORQUE: MIO 19 Nm (14 FT -LB)
U/T1 96 V/T2 97 W/T3 98
1
2
3
Illustration 3.15 Terminal Locations – Left, Front, and Right Views. The gland plate is 42 mm (1.65 in) below 0.0 level.
22
®
VLT
FASTENER TORQUE: MIO 19 Nm (14 FT -LB) FASTENER TORQUE: MIO 19 Nm (14 FT -LB)
U/T1 96 V/T2 97 W/T3 98 U/T1 96 V/T2 97 W/T3 98
Ground bar
Motor terminals
Brake terminals
Danfoss A/S © 04/2016 All rights reserved.
AutomationDrive FC 302
1
2
308.3 [12.14]
253.1 [9.96]
180.3 [7.10]
3
0.0 [0.00]
MG34Q402
