Video and General Performance Verification Procedures

Required Equipment

Table 45: Required test equipment (video and general performance)
Test equipment
Video test signal generator
SD "Cable Clone" cable simulator
HD "Cable Clone" cable simulator
3G "Cable Clone" cable simulator
75 Ω coaxial cables (3 required)
WFM5200 Waveform Monitor Specifications and Performance Verification
This performance verification includes procedures that verify standard and
option-equipped instruments.
Requirements
1080p 59.94 3Gb/s HD signals (required
for option 3G)
100% color bars
SDI Matrix Split Field Pathological
Signal
1080i 59.94 1.5Gb/s HD signals
100% color bars
SDI Matrix Split Field Pathological
Signal
625i 50 270 Mb/s SD signals
100% color bars
525i 59.94 270 Mb/s SD signals
100% color bars
SDI Matrix Split Field Pathological
Signal
Simulate 0 to 300 meters of Belden 8281
equivalent in 25 meter steps.
Simulate 0 to 150 meters of Belden 8281
equivalent in 10 meter steps, 300 kHz to
1.5 GHz range.
Simulate 0 to 150 meters of Belden
1694A equivalent in 10 meter steps,
0.3 MHz to 3 GHz range (required for
option 3G).
RG-6 type coaxial cable with male BNC
connectors, 1 to 2 meters long, suitable
for use to 1500 MHz.
Video and General Performance Verification Procedures
Example
Tektronix TG700 with HD3G7 module
Tektronix TG700 with HDVG7 module
Tektronix TG700 with DVG7 module
Faraday SC75A800B-G
Faraday FFC010A075, FFC020A075,
FFC040A075, and FFC080A075
(available as a boxed set of 4).
Faraday FFE010D075, FFE020D075,
FFE040D075, and FFE080D075
(available as a boxed set of 4).
Belden 8281 or 1694A. Tektronix part
numbers 012-0159-00 or 012-0159-01.
