Specifications

Table 5: SDI Lightning and Diamond modes

Characteristic
Vertical Gain Accuracy
Electronic Diamond
Graticule
Display
Lightning
Detection High Limit
Level
Low Limit
Detection Level Accuracy
Diamond Area Threshold Range

Table 6: Data mode

Characteristic
Digital Waveform
Digital List
Display Format

Table 7: Arrowhead mode (NTSC/PAL composite limit display for SDI inputs)

Characteristic
Signal to Graticule Accuracy
Composite Limit Cursor Accuracy
Detection Level, nominal
Composite Limit Detection Level
Accuracy
Composite Limit Area Threshold
Range
Luma Limit High
Detection
Low
Range,
Typical
4
Performance requirement
± 0.5%
+630 mV to +756 mV in 1 mV steps
-50 mV to +35 mV in 1 mV steps
± 3.5 mV
Performance requirement
Performance requirement
± 1%, 100 IRE (700 mV), and 131 IRE
(900 mV)
± 1.0% at 100 IRE, 110 IRE, 120 IRE, and
131IRE (700 and 950 mV)
± 1.0% at -24 IRE, –33 IRE, and –40 IRE
(-230 and 300 mV)
Detection Level = ± 7 mV of cursor level
WFM5200 Waveform Monitor Specifications and Performance Verification
Reference information
Fully digital system
RGB deflection axis indicated. Upper and
lower halves are separated, to see negative
signals
Displays signal components as follows: Y
vertically Pb horizontally on top half of display
P horizontally on bottom half of display
r
0% to 10%
Reference information
Non-interpolated waveform display. Cursor
identifies selected sample value (hex,
decimal, binary). Cursor inserted on picture
monitor output shows selected line
Sequential list of sample values in table
format. Cursor identifies selected sample
HEX, DEC, BIN
Reference information
(PAL values in parenthesis)
(PAL values in parenthesis)
(PAL values in parenthesis)
Adjustable thresholds, 1% steps
Upper detection level can be set to 100, 110,
120, or 131 IRE (700 mV or 950 mV PAL)
Lower detection level can be set to –24, –33,
and –40 IRE (–230 mV or –300 mV PAL)
0% to 10%
90 to 108%, 0.5% steps
+5 to –6%, 0.5% steps
