NOTE. It is important to press the Enter key even if Status: Enable is
displayed, to ensure that the Embedded Audio is actually turned on.
Press the up/down arrow keys until "Channel" is displayed. Then press
f.
the left/right arrow keys until "Channel 1" appears. Press ENTER.
g. Press the up/down arrow keys until "Frequency" is displayed. Press the
left/right arrow keys to select "50 Hz", then press ENTER.
h. Press the up/down arrow keys until "Amplitude" is displayed. Use the left
/ right arrow keys to select "–35 dBFS", then press ENTER.
i. Press the CANCEL key once to return to AUDIO:GRP-1:Channel. Use
the left/right keys to select Channel:2, then press ENTER.
j. Following the procedure in steps g through i above, set channels 2, 3, and
4 to the values shown at the start of step 1.
k. After setting channels 1–4, press CANCEL twice to return to AUDIO
(EMBEDDED). Press the left/right arrow keys to select "Group 2", then
press ENTER.
l. Enable the Group 2 audio, following step e above.
m. Set Channels 1 through 4 in Group 2 to the values shown at the start of
step 1, following the procedure in steps g through i above.
n. Press CANCEL twice to return to the AUDIO (EMBEDDED) menu.
o. Press COLOR BAR to return to the top level menu and select a color
bar signal.
2. Connect the output of the DVG7 to the SDI 1A input of the instrument under
test.
3. Set the Thumbnail button for tile navigation. (See page 32, Set
Thumbnail/Display Select Button for Tile Navigation.)
4. Press the Display Select (Thumbnail) button and select tile 4.
5. Press and hold the AUDIO button to display the Audio pop-up menu.
6. Select Audio Input > Embedded.
7. Press the AUDIO button to clear the menu.
8. Verify that the level meter bars have a stair step pattern from –35 dB on
channel 1 to 0 dB on channel 8.
9. Press the AUDIO button to clear the menu.
10. Record Pass or Fail for Embedded to Bar Display in the test record.
