Specifications
Table 31: Environmental performance (cont.)
Category
Cooling
Bare instrument (no optional sleeves)
Portable cabinet
Rack cabinet

Supported Input Formats and Allowed References

Table 32: 25 Hz and 50 Hz frame and field rates
Reference format
Input format PAL
720p 25 Hz X
720p 50 Hz X
1080p 25 Hz X
1080sf 25 Hz X
1080i 50 Hz X
1080p 50 Hz X
576i 50 Hz (625) X
PAL 50 Hz X
18
Standards or description
The variable fans provide forced air circulation. Do not block
ventilation openings.
To ensure proper airflow, there must be at least 2 inches of
clearance on both sides of the instrument, at least 2 inches of
clearance from the rear of the instrument, and at least a 0.5 inch
of clearance from the top of the instrument.
Use only a Tektronix portable cabinet to ensure proper airflow
with this instrument. When using the portable cabinet, the same
minimum clearances as the bare instrument (see above) apply.
Use only the Tektronix WFMRACK-NN or WFMRACK-ON rack
adapter for this instrument. To ensure proper airflow when
installing a rack adapter in a closed rack with solid walls, there
must be at least 2 inches of clearance from both sides of the
rack adapter frame to the rack side walls, at least 3 inches of
clearance from the rear of the rack adapter frame to the rack's
back wall, and at least a 0.5 inch of clearance from the top of the
rack adapter to another rack adapter or installed instrument. The
rack intake air to the side vents must not exceed 40 °C.
An X in the following three tables indicates that this combination is supported.
Other combinations within each of these tables may work, but are unverified and
only supported on a best effort basis.
Operation with an input from one of these three tables and a reference from
another table is not supported (for example, a 1080i 50 input will not work with a
1080i 60 reference). Such mismatches may be reported on the display, and/or the
display will "roll" due to the inherent incompatibility between the standards.
720p 25 720p 50
X
X
X
X
X
X
X
WFM5200 Waveform Monitor Specifications and Performance Verification
1080p 25 1080sf 25 1080i 50
X
X
X
X
X
X
X
