Table 24: External reference

Characteristic
Input Type
Operational
Analog Sync Format
Input Signal Level, Typical
Maximum Operating Input Voltage,
Typical
Absolute Maximum Input Voltage,
Typical
Return Loss, Typical
Hum Tolerance, Typical
Signal/Noise Tolerance, Typical

Table 25: Ethernet

Characteristic
IP Address Mode
Rates
SNMP
Connector Type

Table 26: USB

Characteristic
Type
Speed
WFM5200 Waveform Monitor Specifications and Performance Verification
Performance requirement
Performance requirement
1000 Base-T, 100 Base-Tx, and 10 Base-T
Performance requirement
Reference information
Passive loop-through, 75 Ω compensated.
Locks to analog bi-level and tri-level signals
of supported formats. (See Table 32.) (See
Table 33.) (See Table 34.) Reference must
have a frame rate compatible with input.
WFM mode and Line Select derive timing
from external sync.
Picture mode and Data mode do not use
timing from the external reference.
Composite analog NTSC and PAL. Analog
tri-level sync for supported 1080 and 720 line
formats.
1 V ± 6 dB
± 5 V DC
± 5 V DC
> 30 dB to 30 MHz
Operates with 500 mV at 50 or 60 Hz.
p-p
Operates to 25 dB.
Reference information
Supports manual and DHCP.
For instrument control and feedback of
status. Complies with SNMP version 2.
RJ-45 LAN connector supporting 10/100
Base-T.
Reference information
Host
Complies with USB 1.1 and USB 2.0 Full and
Low-Speed specification.
Full Speed operation in accordance with
USB 2.0 spec is 12 Mb/s.
Specifications
