Table 13: ANC data and ARIB

Characteristic
Displays
Alarms

Table 14: Audio bar displays

Characteristic
Modes
Channel Mode
Surround
Mode
Audio Source
Level Meter Resolution
8
Performance requirement
Performance requirement
WFM5200 Waveform Monitor Specifications and Performance Verification
Reference information
Detects ANC data in SDI streams, displays
data from user specified DID and SDID.
Displays Audio Control Packet. Decodes
data for ARIB types B39, B37, B35, TR-B22,
and TR-B23.
Allows Alarms to be set for: ANC Parity, ANC
Checksum, B39 Absence, B37 Absence,
B35 Absence, TR-B22 Absence,
TR-B23 Absence, and Absence of
user specified DID and SDID.
Reference information
The user may configure the response
dynamics (ballistics), reference levels, peak
hold, offset, and scale of the meters to
suit the monitoring needs of the particular
installation or situation.
Any 16 channels configured into 8 pairs with
phase correlation meters between pairs.
Left, Right, Center Lfe, Left surround, Right
surround meters, and an extra channel pair.
Phase correlation meters between L-R, L-C,
C-R, Ls-Rs, L-Ls, R-Rs and the extra pair.
Monitoring digital audio embedded in serial
digital video.
0.056 dB steps at 30 dB scale, from full scale
to –20 dB FS.
XGA Full Screen mode = 510 steps XGA
4-tile mode = 255 steps.
