Incoming Inspection
Ground Closure Remote
42
11. In the lower-right corner of the screen, the time from the LTC input should
be shown. It may be necessary to reset the LTC generator by using the reset
switch.
12. Record Pass or Fail for LTC Decode in the test record.
13. Disconnect the LTC generator.
1. Connect a 525/270 color bar signal to the SDI 1A input.
2. You will need a custom cable for this step.
a. Solder wires to pins 1, 2, 5, 6, 7, 8, and 9 of a male DB9 connector, and
strip the insulation back approximately 1/4 inch on each of the wires.
3. Connect the HD-15 connector to the REMOTE connector on the waveform
monitor.
Preset Recall Test.
4. Restore the Factory Preset. (See page 32, Restore the Factory Presets.)
NOTE.
This test overwrites presets A1 through A4. Save any existing presets to
USB flash memory before doing this procedure.
5. Set the waveform monitor to display a picture in tile 1 and a waveform in the
remaining tiles (WFM, VECTOR, and GAMUT).
6. Save the current settings as preset A1:
a. Press and hold the PRESET button to display the Preset Menu.
b. Select Save Preset > Select Group A > Save A1.
c. Press SEL to save the preset.
d. Briefly press the PRESET button to close the Preset menu.
7. Repeat steps 5 and 6 to create a preset with picture in tile 2 and waveform in
tiles 1, 3, and 4. Save as Preset A2.
8. Repeat steps 5 and 6 to create a preset with picture in tile 3 and waveform in
tiles 1, 2, and 4. Save as Preset A3.
9. Repeat steps 5 and 6 to create a preset with picture in tile 4 and waveform in
tiles 1, 2, and 3. Save as Preset A4.
10. Repeat steps 5 and 6 to create a preset with picture in tiles 1 and 4 and
waveform in tiles 2 and 3. Save as Preset A5.
11. Repeat steps 5 and 6 to create a preset with picture in tiles 2 and 4 and
waveform in tiles 1 and 3. Save as Preset A6.
