LTC Waveform and Decode
WFM5200 Waveform Monitor Specifications and Performance Verification
12. Select Aux Display > Phase Display.
NOTE.
If you do not see the Phase Display, press the Display Select/Thumbnail
button to view the Audio Display full-screen. To view the Phase Display in 4-Tile
mode, check that the other tiles have non-waveform display in them.
13. Press the left arrow key once.
14. Select Phase/Headphone Pair > 1 & 2.
15. Go through the other phase pairs (3 & 4, 5 & 6, 7 & 8) and verify that the
phase display changes as each pair is selected.
16. Record Pass or Fail for Embedded to Lissajous Display in the test record.
1. Restore to Factory Presets. (See page 32, Restore the Factory Presets.)
Test
2. You will need a custom cable for this step.
a. Make a shielded coaxial cable with a male RCA connector on one end.
On the other end connect the coax center conductor to pin 7 and the outer
shield conductor to pin 8 of a male HD-15 connector.
3. Connect the RCA connector on the custom cable to the output of the Timecode
generator. Connect the 15-pin connector to the REMOTE connector on the
waveform monitor rear panel.
4. Connect the TG700 AVG7 CH1 output to the video input of the Timecode
generator. Select any NTSC signal.
5. Connect a 525/270 color bar signal from the DVG7 module to the SDI A input
of the instrument under test.
NOTE.
The DVG7 and AVG7 must be installed in the same TG700 mainframe
so that their outputs are synchronous.
6. Press CONFIG.
7. Select Aux Data Settings > Timecode Source > LTC.
8. Press the OTHER button to display the LTC waveform.
9. The LTC waveform should be displayed in the active tile. The amplitude will
depend on the source. The sync packet should remain at a constant horizontal
location on the sweep.
10. Record Pass or Fail for the LTC waveform in the test record.
