Key to E-QUE front panel lights and controls
Feature
Description
RESET button
A
Pressing the reset button causes the card and all links to momentarily stop
their current activity and to restart.
During the reset, configuration information downloads to the card from the
CPU card. If the entire system is operating except for one E-QUE card press
the reset button for that card only.
Tip:
The reset button is slightly recessed from the front panel to prevent it
from being accidentally pressed. A tool such as a bent paper clip is required to
press this button.
Power supply lights
B
+3.3-Volt Power Supply Light
The matrix's +3.3-volt power supply provides electric current to this green
light. When lit, the light indicates that the +3.3-volt supply is present and
supplying power to the card.
Status lights
C
When lit, a status light indicates successful communication between the
E-QUE card and a connected device such as an active antenna or splitter.
Each of the E-QUE card's 8
ports to which devices can be connected.
LAN DATA light
D
The
green
through the Ethernet port.
LAN LINK light
The
amber
port.
Table 19: Key to E-QUE front panel lights and controls
88
Eclipse HX-Median User Guide
yellow
LAN DATA light illuminates to indicate there is data passing
LAN LINK light illuminates to indicate a connection to the LAN
status lights corresponds to one of 8
