1) The sample rate and the number of configured ports is indicated by a
LED on the front of the E-MADI64 card.
2) The
3) When the number of received channels differs from the number of channels
configured in EHX, the Channel LEDs on the front of the E-MADI64 card
green, oscillating between 2 types of port numbers.
4) When the received sample rate differs from the configured sample rate, the Sample
rate LEDs on the front of the E-MADI64 card
types of sample rates.
5) Audio passes into and out of the E-MADI64 card to the HX-Median backplane.
6.5

Upgrading the E-MADI64 card

The E-MADI64 card is both centrally upgradable (you can upgrade the E-MADI64 thru the
matrix frame, using EHX) and locally upgradeable, using Xilinx software, a PC and a Xilinx
download cable.
For more information, see the Eclipse HX Upgrade Guide.
73 Eclipse HX-Median User Guide
red Error LED on the E-MADI64 card is turned off.
flash green, oscillating between 2
solid green
flash
