Overview

This chapter provides an overview of the Eclipse HX-Median matrix frame, including the
interface cards and interface modules that can be fitted to the frame.
3.1

Eclipse HX matrix frames

There are four types of Eclipse HX matrix frame available from Clear-Com:
Matrix
Eclipse HX-Median
Eclipse HX-Omega
Eclipse HX-Delta
13 Eclipse HX-Median User Guide
Description
The Eclipse HX-Median has slots
for 2 CPU cards, 7 interface cards,
and 8 interface modules in a six
rack unit (6RU) frame.
For more information, see this
guide.
The largest matrix frame in the
Eclipse HX range.
The Eclipse HX-Omega has slots
for2 CPU cards and 15 interface
cards in a six rack unit (6RU)
frame. For more information, see
the Eclipse HX-Omega User
Guide.
The Eclipse HX-Delta has slots for
2 CPU cards, 4 interface cards and
3 interface modules in a three rack
unit (3RU) frame.
For more information, see the
Eclipse HX-Delta User Guide.
