85
Eclipse HX-Median User Guide
System #1
TX2- E-FIB
card#1 - RX2
TX1- E-FIB
card#1 - RX1
System #5
TX1- E-FIB
card#1 - RX1
TX2- E-FIB
card#1 - RX2
Figure 31: Example fiber-optic connection setup
System #2
TX2- E-FIB
card#1 - RX2
TX1- E-FIB
card#1 - RX1
System #4
TX1- E-FIB
card#1 - RX1
TX2- E-FIB
card#1 - RX2
System #3
TX2- E-FIB
card#1 - RX2
TX1- E-FIB
card#1 - RX1
Primary ring
Secondary ring
