Madi Channels - ClearCom Eclipse HX-Median User Manual

Warning: Eye Safety
This LED based single mode transceiver is a Class 1 LED product. It complies with IEC
60825-1/A2:2001 and FDA performance standards for laser products (21 CFR 1040.10 and
1040.11) except for deviations pursuant to Laser Notice 50, dated July 26, 2001.
Normally a protective plug is fitted to the fiber connector to protect the connector from
damage or the entry of foreign materials. The protective plug should only be removed in
order to fit the fiber optic cable. Replace the plug when the cable is unplugged.
Key to E-MADI64 rear panel connectors
Feature
A
B
C
D
6.3

MADI channels

The E-MADI64 card can route up to 64 MADI channels of audio.
Note: The channel modes for the E-MADI64 are 32, 56 and 64. For more information, see
Table 17: E-MADI 64 channel modes.
Each MADI audio channel:
• Carries one (or a mixture of) any of the 512 Eclipse HX-Median backplane
timeslots.
• Is 24 bits in length.
You can configure the input and output gain for each MADI audio channel in EHX and / or
Production Maestro Pro software. The configurable range for MADI audio channels is -72dB
to +18dB.
70 Eclipse HX-Median User Guide
Description
MADI Fiber connector (Tx and Rx)
The connector is a fiber (MM) SFP Duplex LC removable transceiver module
MADI IN coaxial connector
MADI OUT coaxial connector
Video / Word clock coaxial connector
The clock source is either NTSC/PAL Black and burst, Tri Level HD video
sync or AES Word Clock.
Table 15: Key to E-MADI64 rear panel connectors
