Up to four complete system configurations can be stored in the CPU card of the Eclipse
HX-Median, for retrieval and activation when required. The external PC that hosts the EHX
software can store an almost unlimited number of complete system configurations (the
number is only limited by the available memory space on the PC). You can download the
configurations to the Eclipse HX-Median as required.
EHX 7.6 runs on the following versions of Windows:
• Microsoft Windows 7 (32-bit and 64-bit).
• Microsoft Windows 8.1 (32-bit and 64-bit)
• Microsoft Windows Server 2008 SP2 (32-bit and 64-bit).
• Microsoft Windows Server 2008 R2 (64-bit).
Note: Operation on other platforms is no longer supported.
When running EHX on Windows operating systems, the client and server can run on
separate machines connected over a network. You can use EHX to perform a wide range of
configuration tasks, including:
• Assigning labels (names) to ports and user panels.
• Creating point-to-point and fixed group (partyline) communications between
connected audio devices.
• Enabling, limiting or disabling features of any connected user panel or card.
• Configuring connections between matrix frames.
Note: The above list is not definitive. For more information about the capabilities of EHX, see EHX
Help.
The EHX system can be set up to run on a client/server model over a network, allowing the
system administrator to control multiple matrices remotely.
3.6

User panels

The following Clear-Com user panels are compatible with the Eclipse HX-Median:
• V-Series panels, including expansion panels.
• I-Series panels, including expansion panels.
Note: For more information about installing, using and maintaining user panels, and connecting
user panels to the matrix, see either:
• The V-Series Panels Guide.
• The I-Series Panels Guide
