Key to Figure 3: Eclipse HX-Median rear panel
Feature
A
B
C
D
E
3.2.2

Power supplies

The Eclipse HX-Median matrix has two Euro Cassette power supply units that can be
easily installed or removed as needed. One power supply unit can power an entire matrix.
The second unit provides a backup in case of failure or damage to the first unit.
In addition, the two supplies have separate IEC connectors to AC mains, and are designed
for completely automatic and transparent changeover between supplies in the event of a
power outage in one of the AC mains circuits.
An over-temperature sensor is connected to both an audible failure alarm and a warning
light, allowing the system operator to diagnose and correct any power anomalies while the
system remains operational.
Eclipse HX-Median matrices may be fitted with XP (part 740101Z) or Power-One (part
720379Z) power supply units, depending on the date of manufacture.
18 Eclipse HX-Median User Guide
Description
IEC power supply connectors. For more information about the twin power
supplies, see 3.2.2
Power supplies
Spare slots for interface card rear connector panels. All front installed
interface cards require a corresponding rear connector panel. Blank panels can
be installed to unused slots.
The Eclipse HX-Median has 7 slots available for interface cards. For more
information, see 3.3
Interface cards
MVX-A16 analog interface card rear connector panel.
An MVX-A16 rear connector panel has 16 RJ-45 connectors for connecting
intercom panels and interfaces. For more information about MVX-A16 cards,
see 3.3.1
MVX-A16 analog port card
CPU card rear panel. The CPU card rear panel houses connectors for an
external PC, network, interfaces, alarms and other matrices.
Up to 2 CPU cards can be installed to the matrix, but only one rear-panel CPU
card is required. Whichever of the two front-installed CPU cards is acting as
master will work in conjunction with this card. For more information, see
3.2.4 .
CPU card
Interface module slots. The Eclipse HX-Median has 8 built-in interface module
slots. For more information, see 3.4
Table 3: Key to Figure 3: Eclipse HX-Median rear panel
The different types of power supply units must not be mixed in an HX-
Median matrix; if one of the pair of power supplies is replaced it must be
replaced with the same type of power supply unit. If this is not possible both
power supplies must be replaced with power supply units of the same type.
Power-One power supplies are identified by the part number on the front of
the unit. XP units do not have a part number on the front of the unit.
.
.
.
.
Interface modules
