Each E-MADI64 card set comprises:
• A front card with pin reset and various status indicators (including channel quantity,
sample rate, power and diagnostic (active and error) indicators).
• A rear card with a MADI fiber connector, MADI input and output coaxial cable
connectors, and coaxial Video black and burst / Tri Level HD / Word clock sync
input.
3.3.5 IVC-32 IP interface card
The IVC-32 interface allows the Eclipse HX matrix to connect to IP enabled V-Series panels
and Concert users using an IP network.
Each IVC-32 interface comprises:
• A front card with a reset button and various status indicators.
• A rear card with eleven RJ-45 ports giving eight E1/T1 ports (not used), DECT sync
in and out (not used) and a LAN port for IP connectivity.
Each IVC-32 front card has status LEDs for power, port activity and LAN status.
The LAN indicators show whether there is a LAN connection and the IP activity on the LAN
port.
3.3.5.1
You can add an IVC-32 Redundant Card that provides fail-over redundancy for one or more
IVC-32 Cards in the matrix.
An IVC-32 Card will fail-over to the IVC-32 Redundant Card under the following conditions:
• • All configured VoIP ports are unconnected for longer than 90 seconds.
• • The IVC-32 Card is detected as absent from the VME backplane.
• • It is requested via the EHX Event Log.
A switch back from a redundant card back to a failed card only occurs under the following
condition:
• The redundant card has failed. If the original card is still in error, then it will switch
back and forward until corrective action is taken.
3.3.6 LMC-64 interface card
The LMC-64 interface allows the Eclipse HX-Median to provide Production Maestro Pro
(routing software) clients with audio level metering of partylines (conferences) and four-wire
ports over an IP network.
Each LMC-64 interface comprises:
• A front card with a reset button and various status indicators.
22 Eclipse HX-Median User Guide
IVC-32 Redundant Card
