ClearCom Eclipse HX-Median User Manual page 67

Note: Figure 25 shows an unconfigured E-MADI64 card, when all lights are lit to indicate their
location.
Note: On a card with a clock source and MADI connections (where the received MADI signal
matches the card set up), the following lights are lit: the Lock source LED [
Sample rate (Fs) LED [
Error LED [also
Key to E-MADI64 front panel lights and controls
Feature
A
B
C
D
67 Eclipse HX-Median User Guide
D ], the Channels LED [
F ] is lit when there is no clock source or MADI input.
Description
Reset button
Pressing the Reset button causes the card and all links to momentarily stop
their current activity and to restart. The
when the reset starts and comes back on when the reset is complete.
During the reset, configuration information downloads to the card and its
connected matrices from the CPU card. If the entire system is operating
except for one E-MADI64 card, press the reset button for that card only.
Tip: The reset button is slightly recessed from the front panel to prevent it
from being accidentally pressed. A tool such as a bent paper clip is needed to
press this button.
+3.3-Volt Power Supply LED
The matrix frame's +3.3-volt power supply provides electric current to this
green light. When lit, the light indicates that the +3.3-volt supply is present and
supplying electric current to the card.
Lock source
A green light indicates that the E-MADI64 card has locked to the clock source
(either video (VID) or Word Clock (WRD)).
Sample rate or Sf (Sampling frequency)
A green LED indicates the current sampling rate of the MADI channels. The
sample rate is determined in EHX when a video sync is used, or automatically
detected from the clock source when a Word clock is used.
Note:
If the quantity of channels is 32, the sampling rate is either 44.1KHz, 48KHz or
96KHz.If the quantity of channels is either 56 or 64, the sample rate is either
44.1KHz or 48KHz.
The Sample rate LED on the front of the E-MADI64 will oscillate between two
sample rates when the received sample rate differs from the transmitted
sample rate.
E
] and the Active LED [
flashing green Active light goes off
C ], the
]. The
F
