11

Maintaining the Eclipse HX-Median

The Eclipse HX-Median matrix system connects a complex network of microprocessor
controlled devices.
Due to the complexity of the system, field service should be limited to isolating a problem to
the specific circuit board that may be causing the problem. Once the circuit board has been
identified, it can be either repaired or replaced.
Note:
For an overview of the Eclipse HX-Median, see 3 Overview.
11.1

Routine maintenance recommendations

11.1.1

Cleaning the matrix frame

Because the matrix has moving air in it, the entire matrix should be cleaned at least once a
year. To clean the matrix, shut off AC power, remove all cards, and use compressed air to
remove any dust buildup in the matrix itself. Clean all cards with a brush to remove dust
buildup.
11.1.2

Spare parts

To facilitate quick repair of the system with minimum downtime, Clear-Com recommends
keeping the following spare system components in good working condition at all times:
• One CPU card.
• One CPU interface card.
• One Euro Cassette power supply module of the type fitted to the matrix.
• One of each type of intercom panel in the system.
110
Eclipse HX-Median User Guide
Servicing instructions are for use by qualified personnel only. To reduce
the risk of electric shock, do not perform any servicing other than that
described by this guide, unless qualified to do so. Refer all servicing to
qualified service personnel.
Care should be taken not to induce a static discharge in the cards. Use
of a grounding wrist strap is recommended. If a grounding wrist strap is
not available, touch an unpainted metal surface on the matrix chassis
periodically to neutralize static electricity.
