12.8

E-MADI64 fiber transceiver

Category
Type
Wavelength
Connector
Standard Max Node Length
Note: The standard multimode fiber module is a Class 1 LED Product. The optional single mode fiber
module is a Class 1 Laser Product.
12.9

E-MADI64 clock sources

Clock type
Word Clock
SD Video
HD Tri-Level Sync
120 Eclipse HX-Median User Guide
Measures / comments
Multimode SFP Transceiver
1310nm
Duplex LC
2km (other distances (achieved using the
optional single mode fiber module) are available
to special order.)
Table 32: E-MADI64 fiber transceiver
Clock source
44.1KHz
48KHz
96KHz
NTSC
PAL
720P60
720P59.94
720P50
720P30
720P27.97
720P25
720P24
720P23.98
1080P60
1080P59.94
1080P50
1080P30
