Key to IVC-32 rear panel connectors
Feature
A
B
C
D
Note: The E1/T1 and DECT ports are not used on the IVC-32 interface and should not be
connected.
9.3 IVC-32 interface applications
The IVC-32 interface may be used to connect:
• V-Series IP panels to an Eclipse matrix.
• Provide a link to a Concert Instant Voice Router (IV-R) server.
9.3.1

V-Series IP Panels

V-Series panels with V5.1 or later software may be enabled to communicate with an Eclipse
HX-Median matrix over an IP network using the IVC-32 interface card.
The advantage of using IP communication is that it enables remote panels to communicate
over an existing local (LAN) or wide area (WAN) network rather than requiring a dedicated
link.
9.3.2

Concert Users

The IVC-32 interface will allow Concert users to establish audio links with users on the
Eclipse matrix via the Concert IV-R server.
This server will provide a link over IP between Concert users and the Eclipse matrix.
Concert users cannot connect directly to the IVC-32 interface card.
Concert users communicate with Eclipse users using a soft-panel, rather than the main
Concert Client application.
103 Eclipse HX-Median User Guide
Description
LAN port (RJ-45)
DECT sync ports:
DECT Ref in (Not used)
DECT Ref out (Not used)
E1 / T1 Port 1 - 4 (Not used)
E1 / T1 Port 5 - 8 (Not used)
Table 22: Key to IVC-32 rear panel connectors
