The MVX-A16 analog port card sends balanced audio and RS-422 data signals to connected
audio equipment through 4-pair shielded CAT5 cable. The card connects up to 16 audio
devices (such as user panels, interfaces, or four-wire audio equipment) to the central matrix.
Each audio device connected to an analog port card communicates with all other audio
devices in the system and with the central matrix.
3.3.1.1
For intelligent linking, shielded CAT5 cable is run from a port on one Eclipse HX-Median
matrix to a port on a second Eclipse HX-Median matrix to form a trunkline connection.
3.3.2

E-FIB fiber card

E-FIB fiber interfaces connect Eclipse HX matrices together to provide a high speed, dual
redundant link to transfer audio samples and data between systems. These connections can
be configured to provide protection against the loss of a link or a node. E-FIB cards should
be installed in the last port slot.
Each E-FIB fiber interface card set comprises:
• A front card with various status indicators.
• A rear card with two Duplex LC Terminated fiber optic connectors (TXVRA and
TXVRB).
3.3.3

E-QUE E1/T1 interface card

The E-QUE E1/T1 interface allows the Eclipse HX-Median to connect to
FreeSpeak/CellCom/ FreeSpeak II antennas, FreeSpeak/CellCom/ FreeSpeak II antenna
splitters, and E1 and T1 trunk lines.
Each E-QUE interface card set comprises:
• A front card with a reset button and various status indicators.
• A rear card with eleven RJ-45 ports giving eight standard Ethernet ports, DECT
sync in and out and a LAN port for diagnostic use.
Each E-QUE front card has status LEDs for power, port activity and LAN status. The port
activity LEDs show when:
• A device is connected to an E1 port.
• A connection has been established between the E1 port and the connected device.
3.3.4

E-MADI64 interface card

The E-MADI64 is a MADI (Multichannel Audio Digital Interface) card, providing up to 64
duplex channels of AES3 digital audio over a coaxial cable or fiber pair between compatible
devices.
Note: You have the option in EHX to limit the E-MADI64 card to either 32, 56 or 64 channels of
audio. All MADI channels have standard EHX settings, including VOX and in-use tally. See
also 6E-MADI64 card.
