10 LMC-64 metering card
The Level Meter Card (LMC-64) interface card enables the Eclipse HX-Median to provide
audio level metering for Production Maestro Pro over a network.
Each LMC-64 interface card can meter up to 64 virtual partylines (conferences) and four-
wire ports.
The LMC-64 interface comprises:
• A front card with a reset button and various status indicators (including status LEDs
for power, port activity and LAN status).
Note:
• A rear card with eleven RJ45 ports giving eight E1/T1 ports (not used), DECT sync
in and out (not used) and a LAN port used for the IP connection.
Note: An Ethernet cable must be connected to the LMC-64 interface LAN port for the card to
function correctly.
Note: For an overview of the Eclipse HX-Median, see 3 Overview.
105 Eclipse HX-Median Matrix User Guide
The port activity LEDs are inactive on the LMC-64 front card as the E1/T1
ports are not used.
