Key: Eclipse HX-Median front panel
Feature Description
Interface module slots (unused in this example). The Eclipse HX-Median
A
can house up to 8 interface modules. Blank panels can be installed to unused
slots. For more information about interface modules, see 3.4
CPU cards (P1 and P2). 2 CPU cards are supplied with the matrix, but only
B
one rear-panel CPU card is required. Whichever of the two front-installed CPU
cards is acting as master will work in conjunction with this card. For more
information, see 3.2.4
Interface cards. Up to 7 interface cards can be installed to the matrix. Blank
C
panels can be installed to unused slots. For more information, see 3.3
.
cards
In Figure 2, the cards shown in slots 1 and 2 are MVX-A16 analog port cards.
MVX-A16 cards are used to connect user panels and interfaces. For more
information about MVX-A16 cards, see 3.3.1
Twin power supplies. The two Euro Cassette power supply units can be easily
D
installed or removed as required. One power supply unit can power an entire
matrix. The second unit provides a backup in case of failure or damage to the
first unit. For more information, see 3.2.2
16 Eclipse HX-Median User Guide
CPU card
Table 2: Key to Eclipse HX-Median front panel
.
MVX-A16 analog port card
Power supplies
Interface modules
Interface
.
.
.
