E1/T1 Matrix To Matrix Straight Cable Connections; E1 To Freespeak / Cellcom / Freespeak Ii™ Antenna Straight Cable Connection - ClearCom Eclipse HX-Median User Manual

For E1 and T1 direct matrix to matrix connections the CAT5 crossover cables should be
wired, as shown in the table below:
Matrix 1 Pin
1
2
3
4
5
6
7
8
4.8

E1/T1 Matrix to Matrix straight cable connections

E1/T1 straight cables may be used to connect E1 or T1 ports to E1 or T1 networks or third
party equipment, as shown in the table below:
Matrix 1 Pin
1
2
3
4
5
6
7
8
4.9 E1 to FreeSpeak
straight cable connection
Straight CAT5 cables are used to connect an E-QUE card to a FreeSpeak / CellCom /
FreeSpeak II antenna or splitter.
The E1 pinout for connecting an antenna or splitter is shown in
Table 10: E1 pinout for connecting a FreeSpeak / CellCom / FreeSpeak II antenna or
splitter.
46 Eclipse HX-Median User Guide
Description
To
To
Not connected
To
To
Not connected
Not connected
Not connected
Table 7: E1/T1 Crossover cable
Description
To
To
Not connected
To
To
Not connected
Not connected
Not connected
Table 8: E1/T1 Straight cable
® ®
/ CellCom / FreeSpeak II™ antenna
Matrix 2 Pin
4
5
3
1
2
6
7
8
Matrix 2 Pin
1
2
3
4
5
6
7
8
