5.7.1

Conditions that cause an alarm

The following conditions trigger an alarm:
• If any of the voltages produced by the first power supply unit fall below normal
levels.
• If any of the voltages produced by the second power supply unit fall below normal
levels.
• If an internal matrix alarm condition activates a matrix relay to turn on an external
alarm.
• If the active CPU card exceeds a temperature threshold.
• If either of the CPU cards is removed from the matrix.
• If either of the matrix's two cooling fans stop operating.
• If the temperature inside the Eclipse matrix exceeds a set threshold.
5.7.2

Main alarm light

An alarm condition triggers the following events:
• The
• The matrix's internal alarm buzzer sounds.
Any installed alarm relay outputs switch to active (the normally open contact closes and the
normally closed contact opens). When the alarm relay activates, it can cause an externally
connected device like a light or buzzer to switch on.
One of the six auxiliary
of the alarm condition (see 5.7.4 Auxiliary alarm lights).
5.7.3

Alarm reset button

When the alarm reset button is pressed the following events take place, even if the alarm
condition has not been corrected:
• The internal audible alarm buzzer stops buzzing.
• Any wired relay contacts return to their inactive state. If these relays are connected
to external alarm lights or alarm buzzers, those lights or buzzers shut off.
• If the original alarm condition still exists, the red main alarm light on the matrix's
front panel continues to flash. The red main alarm light only stops flashing when all
original sources triggering the alarm are corrected.
• If a new alarm condition or conditions occur before the original alarm conditions are
corrected, the internal buzzer and relay contacts will not reactivate. They will only
reactivate after all original alarm conditions are corrected.
60 Eclipse HX-Median User Guide
red main alarm light flashes.
red alarm lights may go on, to more precisely indicate the source
