Note:

For information about diagnosing power supply issues, see 5.7 Diagnosing power supply

problems.

3.2.3

Main features of the Eclipse HX-Median

Features of the Eclipse HX-Median matrix system include:

• A six rack-unit (6RU) frame.

• Full audio bandwidth throughout the signal chain, producing superior broadcast

audio quality. The system maintains 24-bit depth, a sampling rate of 48 kHz, and 30

Hz to 22 kHz frequency response.

• Support for 7 analog port interface cards (MVX-A16), providing 16 analog ports

each.

• Support for 8 interface modules, which you can use to connect the matrix to

telephones, two-way radios, camera intercoms, partylines, and other forms of

communication.

• Fail-safe redundancy is achieved with two CPU cards and two power supplies.

Note:

Power supplies automatically switch to the correct voltage, for compatibility around the

world.

• Eight general purpose inputs and eight relays, located directly on the matrix.

• Full compatibility with V-Series and I-Series user panels.

• Matrices that link across cities, nations, or continents through trunk lines.

• Uses the same fiber-networking interface as the Eclipse HX-Omega matrix.

• Connection to FreeSpeak/CellCom/FreeSpeak II antennas and splitters using the E-

QUE interface card.

• Connection to IP enabled V-Series panels and Concert users over IP networks

using the IVC-32 interface card.

• Audio level metering over IP networks using the LMC-64 interface card.

• Up to 64 duplex channels of AES3 audio over a coaxial cable or fiber pair using a

single E-MADI64 interface card.

• VOX-programmable audio, which visually cues you at the matrix when audio

transmits at a programmed threshold on a connected user panel or interface.

• Visual and intuitive EHX configuration software.

Note:

The number of interface cards that can be fitted to the matrix is limited by port count. For

more information, see 4.4.3 Combining interface cards in the frame.
