IRIS IRMA MATRIX 2 Installation Manual page 82

Index
Production status
Unit
mm (inch)
free size tolerances
DIN ISO 2768 mK
edge of workspace
DIN ISO 13715
Description of change
infrared & intelligent sensors
www.irisgmbh.de
Material
Discription
Drilling template IRMA MATRIX, Flush mount with threade bolt
Drawing-No.
BB_DIST500-E
+1
53
28±0.5
iris-GmbH
Date Editor Approved
Date
Creator JP
1 / 3
Page
iris-
Part-No.
Surface
Scale A4-Format
1:1
Index
00
Name
05.12.14
