- Page 1 IRIS Touch 600 Range Dialler Installation Manual Version 1.3...
- Page 3 The information contained is supplied without liability for any errors or omissions. No part may be reproduced or used except as authorised by contract or other written permission. The copyright and foregoing restriction on reproduction and use extend to all media in which the information may be embedded.
-
Page 5: Table Of Contents
6.3. Post configuration tests ..............13 6.4. Alarm panel management ..............13 Relay outputs ..................... 14 Troubleshooting ..................14 Appendix A – Installation photo/screen shots ........... 15 Appendix B – Specification ................16 IRIS Touch 600 Range Dialler Installation Manual... -
Page 7: Introduction
1.1. This manual is designed to help you, the Installer, with the installation process for the IRIS Touch alarm dialler. We recommend that you read through this manual, in its entirety, before you visit the customer’s site and begin the installation. -
Page 8: 1.2. Overview
IP transmission system of choice for Monitoring Centres across Europe. The IRIS 600 series is a PCB format unit intended to be used in the following situations: The alarm panel can communicate with the IRIS card via a serial/RS485 interface on the IRIS. -
Page 9: System Specifications
1.3. System specifications Feature IRIS Touch 620 IRIS Touch 640 Ethernet Ethernet & GPRS Serial data connection for direct connection to alarm panel RS485 data connection for direct connection to alarm panel Alarm transmission and panel... -
Page 10: Before You Start
Mask for the IRIS dialler. An additional long Ethernet CAT5 cable, in case the installation site requires one longer than that supplied with the IRIS dialler. Cable lengths up to 100m are allowable. A SIM card enabled for GPRS with the PIN code clear. (Ethernet & GPRS only.) -
Page 11: Indicators
Indicators The IRIS Touch diallers have LED indicators that have the functions described below: Name Function On when Ethernet connected and synchronised GPRS On when GSM registered. (Ethernet & GPRS only.) POLL On when successfully polling with Monitoring Centre. Note: Flickers Off to show each poll. -
Page 12: Installation For Pin Alarms
Installation for PIN alarms The IRIS Touch dialler has PIN inputs that can be used to generate alarm messages. These can be: Text messages via SMS. ((Ethernet & GPRS only.) SIA alarm messages over IP to the Monitoring Centre. Fast Format alarm messages over IP to the Monitoring Centre. -
Page 13: Installation
It is also possible to link the contacts to the IRIS dialler via sense resistors so that an open or short circuit tamper on the loop can be detected and the Monitoring Centre alerted. In this case the connections should be made as... -
Page 14: Configuration
4.2. Configuration Configuration is performed by using the virtual touch screen within Chiron’s IRIS dialler configuration software running on a PC or Laptop which is connected to the dialler via the USB interface. This screen gives access to the Installation Wizard that guides you through the setup process. -
Page 15: Installation For Use With Galaxy Panels
Installation for use with Galaxy panels 5.1. Installation Use the following procedure to install the IRIS Touch dialler for use with Galaxy panels: Install the IRIS Touch dialler inside the existing alarm panel enclosure and fix with the self-adhesive feet. - Page 16 The configuration menu on the Galaxy panel for the Ethernet card is found at location 56 (Communications) entry 4 (Ethernet). If the IRIS dialler is not set to the defaults, default it by clearing the Primary IP address on the Galaxy (menu 02, entry 2). Check that the SERIAL LED is showing ‘Not Configured’.
-
Page 17: Post Configuration Tests
5.5. Alarm panel management The IRIS adapter acts as a conduit for remote configuration of the Galaxy panel and remote keypad operation using Honeywell’s RSS software running with direct IP connection on the PC. Incoming and outgoing calls are supported: Incoming calls (from RSS) are initiated using the fixed IP address set for the adapter and the default Galaxy port number ‘10001’. -
Page 18: Installation With Texecom Panels
Installation with Texecom panels 6.1. Installation Use the following procedure to install the IRIS Touch dialler with Texecom panels: Install the IRIS Touch dialler inside the existing alarm panel enclosure and fix with the self-adhesive feet. Plug the Ethernet cable (cream) between the socket... -
Page 19: Post Configuration Tests
6.4. Alarm panel management The IRIS adapter acts as a conduit for remote configuration of the panel and remote keypad operation using Texecom’s Wintex software running with direct IP connection on the PC. Incoming and outgoing calls are supported: the IP address of the PC running the Wintex software. -
Page 20: Relay Outputs
Check that there is power to the system IRIS dialler is connected to the and that the wiring is the correct polarity. power. Serial LED flash pattern Alarm panel serial/RS485 interconnect indicates no connection to the fault. panel. IRIS Touch 600 Range Dialler Installation Manual...
