IRIS IRMA MATRIX 2 Installation Manual page 6

6/74 IRMA MATRIX R2 CAN Installation manual
released
Fig. 30:
Fig. 31:
Fig. 32:
Fig. 33:
Fig. 34:
Fig. 35:
Fig. 36:
Fig. 37:
Fig. 38:
Fig. 39:
Fig. 40:
Fig. 41:
Fig. 42:
Fig. 43:
Fig. 44:
Fig. 45:
Fig. 46:
Fig. 47:
Fig. 48:
Rev. 1.6 2018-09
"Installation" / representation "Function Area Address" on the vehicle ...... 49
Installation parameters section - Parameters in the door area at a glance 50
Sector "Function area/door" - FA on product label (framed in yellow) ........ 50
Sector "Mounting Height"........................................................................................ 51
Sector "Wall Distance (Left, Right)" ....................................................................... 52
Sector "Door To Sensor Distance" ........................................................................... 52
Sector "Vehicle Edge Offset" .................................................................................... 53
Sector "Rotation Angle X" ......................................................................................... 53
Sector "Door Clearance (Left, Right)" ..................................................................... 54
Sector "Door Opening Angle (Left, Right)"............................................................ 54
On the left: start the "A21_Assistent" software / on the right: splash
screen of "A21_Assistent" ........................................................................................ 56
Configuration menu for IRMA gateway ............................................................... 57
Flowchart (protocol variants: IBIS, IRMA (UIP), J1708) ..................................... 60
Flowchart for checking the counting operation ................................................. 61
Sensor installation in a 3-door vehicle with sCON-S (standard) for
CAN - IRMA gateway at the beginning (M12 connector) ................................. 69
Sensor installation in a 4-door vehicle with sCON-S (standard) for
CAN - IRMA gateway in the center (M12 connector) ........................................ 70
Sensor installation in a 3-door vehicle with sCON-F-12 - IRMA gateway
at the beginning (M12 connector) ......................................................................... 71
Sensor installation in a 4-door vehicle with sCON-F-12 - IRMA gateway
in the center (M12 connector) ................................................................................ 72
CAN installation in a 4-door articulated vehicle (direct connection to the
on-board computer, second power supply on the CAN BUS) ......................... 73
