Symbols/abbreviations/designations used

"Please note!"
"Caution - can result in defects"
"See Annex"
"Instructions"
"Please contact iris-GmbH"
Setting parameters during configuration are identified as shown on the left.
"Door Polarity"
iris product designation
M12CAN-CON-03
Female connector
Connector (f)
Male connector
Connector (m)
CAN type M12
5-pole M12 connector (m/f) with A coding, see section 1.3.1, p. 9
connector (m/f)
ETH type M12
4-pole M12 connector (m/f) with D coding, see section 1.3.2, p. 9
connector (m/f)
Cable type CAN
Cable with 5-pole connectors (m/f), CAN type
Cable with 4-pole connectors (m/f), ETH type
Cable type ETH
Operating instructions for software
Marked grey
This arrow indicates sensor setting parameters which must be adjusted to their environment on each installation.
This section applies to installations with the sCON (standard) connector.
This section applies to installations with sCON-F-12
This section does not apply to installations with MATRIX sensors of the surface mount version.
sCON Abbreviation of the connector for IRMA MATRIX sensors
sCON-S Connector (standard) for IRMA MATRIX sensors of the flush mount and surface mount versions
sCON-F-12 Connector for IRMA MATRIX sensors of the flush mount version
x, y Variable cable lengths or variables in general
Serves as a variable. In the item description it has the following meaning: the product is available in different cable
-Kn-
characteristics. For the description of the cable characteristics K01 – K05 (formerly K2, K3), see section 5.1
-XX- In the product designation: cable available in different cable characteristics (K2, K3)
VP+/VP- Power supply of sensor
CAN-H/CAN-L CAN BUS communication
Ethernet / CAN type interface
ETH/ CAN
