Irma-Gateway-4-Ibis And Irma-Gateway-4-Rs485.2 - IRIS IRMA MATRIX 2 Installation Manual

38/74 IRMA MATRIX R2 CAN Installation manual
released
7.1.1

IRMA-Gateway-4-IBIS and IRMA-Gateway-4-RS485.2

The connections listed below apply to units IRMA-Gateway-4-IBIS and IRMA-Gateway-4-
RS485.2
Table 7: Door contact with evaluation of potential free switches
Pin
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
Rev. 1.6 2018-09
Use
Jumper to pin 8
Jumper to pin 7
Switching input_1, contact "b"
Switching input_1, contact "a"
Jumper to pin 12
Jumper to pin 11
Switching input_2, contact "b"
Switching input_2, contact "a"
Jumper to pin 16
Jumper to pin 15
Switching input_3, contact "b"
Switching input_3, contact "a"
Jumper to pin 20
Jumper to pin 19
Switching input_4, contact "b"
Switching input_4, contact "a"
Wire color
Black
Black
Blue
Grey
Black
Black
Violet
Orange
Black
Black
Brown
White
Black
Black
Green
Yellow
