IRIS IRMA MATRIX Door Clear Mounting And Operating Instructions

Infrared motion analyzer 5th generation for sensor versions: dist500-f, dist500-a
Table of Contents

Advertisement

Quick Links

Automatic Passenger Counting
IRMA – Infrared Motion Analyzer
th
5
generation
IRMA MATRIX
Door Clear option
Mounting and operating instructions
For sensor versions:
DIST500-F
DIST500-A
iris-GmbH | Ostendstrasse 1 – 14 | 12459 Berlin | Germany
www.irisgmbh.de
Rev. 1.3 | 2018-08
Subject to alterations!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IRMA MATRIX Door Clear and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for IRIS IRMA MATRIX Door Clear

  • Page 1 IRMA – Infrared Motion Analyzer generation IRMA MATRIX Door Clear option Mounting and operating instructions For sensor versions: DIST500-F • DIST500-A • iris-GmbH | Ostendstrasse 1 – 14 | 12459 Berlin | Germany Rev. 1.3 | 2018-08 www.irisgmbh.de Subject to alterations!
  • Page 2 2/30 IRMA MATRIX Door Clear option | Mounting and operating instructions released Document information Title of document: IRMA MATRIX Door Clear option | Mounting and operating instructions File name: KDBA_IRMA-MATRIX_Door Clear-option_Mounting_and operating_instructions_1.3_en.pdf Revision: Edition (YYYY-MM): 2018-08 Type of document: Customer documentation...
  • Page 3: Table Of Contents

    3/30 IRMA MATRIX Door Clear option | Mounting and operating instructions released Table of contents General information ..................... 4 Symbols used / Abbreviations ....................4 What is Door Clear?........................5 Mounting IRMA MATRIX ....................6 Placing the IRMA MATRIX sensor ....................6 Connection via Ethernet ......................
  • Page 4: General Information

    4/30 IRMA MATRIX Door Clear option | Mounting and operating instructions released Fig. 12: Select sensor ..........................13 Fig. 13: Confirm sensor selection with OK ..................14 Fig. 14: Left: currently set Door Clear zone ..................14 Fig. 15: View after applying DELETE ..................... 15 Fig.
  • Page 5: What Is Door Clear

    5/30 IRMA MATRIX Door Clear option | Mounting and operating instructions released What is Door Clear? The licensed IRMA MATRIX sensor (release 2) Door Clear feature can, in addition to passenger counting, detect the presence of persons and objects in the function area.
  • Page 6: Mounting Irma Matrix

    6/30 IRMA MATRIX Door Clear option | Mounting and operating instructions released 3 Active Door Clear zone 4 Sensor´s field of view Mounting IRMA MATRIX Placing the IRMA MATRIX sensor In addition to the installation instructions for CAN and Ethernet wiring, please note the following points when placing the sensor especially for Door Clear: •...
  • Page 7: Connection Via Can Direct Integration

    7/30 IRMA MATRIX Door Clear option | Mounting and operating instructions released IRMA MATRIX Surface mounted version Fig. 2: Signal chain for Door Clear in ETH wiring Connection via CAN direct integration For a 2-door bus (middle door: approx. 1.25m x 2.10m) with two IRMA MATRIX sensors, for...
  • Page 8: Connection Via Gateway Ibis And Door Control Analyzer

    8/30 IRMA MATRIX Door Clear option | Mounting and operating instructions released Connection via gateway IBIS and door control analyzer For a 2-door bus (middle door: approx. 1.25m x 2.10m) with two IRMA MATRIX sensors, for example, mount via gateway IBIS as follows: follow the instructions in the document KDIA_IRMA-MATRIX_R2_Installationsanleitung-CAN_1.5, available at...
  • Page 9: Connecting The Sensor To The Pc

    9/30 IRMA MATRIX Door Clear option | Mounting and operating instructions released voltages. ‘b’ contact ‘a’ contact Door Clear door 4 ‘b’ contact Note Fig. 5 for the “V” outputs of the door control analyzer: Fig. 5: Pin assignment for Door Clear on the door control analyzer Connecting the sensor to the PC To configure the sensor and Door Clear, you need a laptop with Windows XP, Vista, 7 or 8.
  • Page 10: Pc Connection Via Ethernet

    10/30 IRMA MATRIX Door Clear option | Mounting and operating instructions released 2.5.1 PC connection via Ethernet Connect the sensor to the RJ45 connector of the PC using the appropriate adapter cable. To do this, the sensor Ethernet interface must be connected to the PC via an ETH switch and a KQ-M12CAT5- RJ45-01-2m (xm) adapter cable.
  • Page 11: Configuring Door Clear

    11/30 IRMA MATRIX Door Clear option | Mounting and operating instructions released Using a CAN USB converter (accessory from softing), connect the sensor via to a USB connector on the PC. The sensor must be connected to the CAN-USB converter via a sCON-S-CAN-ETH-23- K2-x-y or sCON-F-12 connector.
  • Page 12: Configuring Door Clear In The Dc Configurator

    12/30 IRMA MATRIX Door Clear option | Mounting and operating instructions released Configuring Door Clear in the DC Configurator Clicking on starts the DIST500-Door ClearConfigurator.exe program. Program start-up After opening the Door Clear configurator, please note the instructions which appear in the main window: “The door must be closed and the OBC disconnected to...
  • Page 13: Fig. 11: Program Restart With Application Note

    13/30 IRMA MATRIX Door Clear option | Mounting and operating instructions released Restarting after changing language settings Restart Door Clear-Configurator in accordance with the instructions. Fig. 11: Program restart with application note Select sensor Select the corresponding sensor via click on SENSORAUSWAHL (= sensor selection).
  • Page 14: Fig. 13: Confirm Sensor Selection With Ok

    14/30 IRMA MATRIX Door Clear option | Mounting and operating instructions released Confirm sensor selection Select the corresponding sensor and click OK. Fig. 13: Confirm sensor selection with OK Setting the Door Clear Zone Sensor device number Exterior (outside the vehicle) Optical axis (see p.
  • Page 15: Fig. 15: View After Applying Delete

    15/30 IRMA MATRIX Door Clear option | Mounting and operating instructions released Configuring the Door Clear zone in the vertical (z-plane) In the “Height range”, you can adjust the height of the Door Clear zone using the controller on the z-plane, e.g. to ignore disturbing door functional elements in the upper or lower range.
  • Page 16: Fig. 16: Door Clear Zone

    16/30 IRMA MATRIX Door Clear option | Mounting and operating instructions released Exterior Reconfiguring the Door Clear zone around the optical axis. By clicking on the diagonal corner points, you can define the Door Clear zone and remove it again by clicking LÖSCHEN (= delete).
  • Page 17: Fig. 17: Test Run Active, The Sensor Sets The "Door Clear" Status

    17/30 IRMA MATRIX Door Clear option | Mounting and operating instructions released Start test run The Door Clear function is active. The “Tür frei (= door clear)” sensor status is set. The Door Clear zone is clear in the respective x-, y- and z-zones.
  • Page 18: Applying Door Clear In The Config Tool

    18/30 IRMA MATRIX Door Clear option | Mounting and operating instructions released Exit Door Clear configurator Quit the Door Clear configurator using EXIT. Fig. 19: Exit Door Clear configurator Applying Door Clear in the Config Tool Close the DC configurator before opening the Config Tool. The sensor can only communicate with one tool at a time.
  • Page 19: Fig. 20: "Door Clear" Tab In The Config Tool

    19/30 IRMA MATRIX Door Clear option | Mounting and operating instructions released Open the Config Tool. If necessary, check the firmware version to avoid a compatibility issue (see p. 11). In the “Installation” tab, set all parameters according to the installation situation.
  • Page 20: Fig. 21: Writing The Configuration Data Into The Sensor

    20/30 IRMA MATRIX Door Clear option | Mounting and operating instructions released  All parameters are written into the sensor by the Config Tool. Fig. 21: Writing the configuration data into the sensor Rev. 1.3 2018-08...
  • Page 21: How Does Door Clear Work

    21/30 IRMA MATRIX Door Clear option | Mounting and operating instructions released Then, the sensor is restarted and the Config Tool appears showing the main menu. How does Door Clear work? Activating Door Clear If the Door Clear feature is included in the sensor firmware, the licensed Door Clear feature is automatically activated when commissioning the IRMA MATRIX sensor.
  • Page 22: Door Clear Limitations And Conditions Of Use

    22/30 IRMA MATRIX Door Clear option | Mounting and operating instructions released Door Clear limitations and conditions of use What do I have to consider when installing and commissioning Door Clear? The following overview describes the characteristics of Door Clear, its application limitations in the function area and which measures you may have to take.
  • Page 23 23/30 IRMA MATRIX Door Clear option | Mounting and operating instructions released Fig. 14) Mounting height There is a rule of thumb: place the sensor at least as The opening angle of the sensor´s field of view α is approx.:...
  • Page 24: Reversing The Door Status

    24/30 IRMA MATRIX Door Clear option | Mounting and operating instructions released display depends on how long the sensor was disappears within minutes if left previously active and how long the object does not untouched. The Door Clear status change its shape.
  • Page 25 25/30 IRMA MATRIX Door Clear option | Mounting and operating instructions released using sCON-S (pg. 28), • • using sCON-F-12 (pg. 29) and • using sCON-F-12-PoE (pg. 30). Rev. 1.3 2018-08...
  • Page 26 26/30 IRMA MATRIX Door Clear option | Mounting and operating instructions released IRMA MATRIX sensor (built-in version) Sealing cap sCON connector for M12 voltage supply cable sCON-S-CAN-22-Kn-1-2m CAN connection Fuse M12 extension cable, CAN type, K-M12CAN-XX-x Adapter cable M12 to SubD9 K-A21-M12CAN-0x-32cm...
  • Page 27 IRMA MATRIX Door Clear option | Mounting and operating instructions released IRMA MATRIX sensor (built-in version) M12 voltage supply cable sCON connector for Fuse sCON-S-CAN-22-Kn-1-2m CAN connection Still to be defined 10 Sub-D9 male connector for CAN connection M12 extension cables, CAN type, K-M12CAN-XX-x M12-CAN-H distributor (opt.
  • Page 28 IRMA MATRIX Door Clear option | Mounting and operating instructions released IRMA MATRIX sensor (built-in version) 7 KQ-M12CAT5-RJ45-01-xm adapter cable for PC D1, D2 Function area 1 and 2 sCON-S-Connector for sCON-S-ETH-22- connection for support services M12 female Kn-1-2m Ethernet connection...
  • Page 29 IRMA MATRIX Door Clear option | Mounting and operating instructions released Rev. 1.3 2018-08...
  • Page 30 IRMA MATRIX Door Clear option | Mounting and operating instructions released Rev. 1.3 2018-08...
