IRMA MATRIX R2 CAN Installation manual
released
• The passengers show purposeful behavior and can mount the vehicle and alight from it
walking upright. If the passengers jump and skip, this hampers optimum counting; the
same applies to persons mounting the vehicle and alighting from it between stops
without a platform compensating the height difference.
12

Annex A

12.1

Mounting variants of IRMA MATRIX sensors

The connection of the IRMA MATRIX sensor to the power supply and the CAN BUS is made
with specially developed connectors which are available in different versions with different
functionalities and properties. For an overview see section 12.1.2 on p. 64.
12.1.1

Mounting sets

The mounting set required for attaching a MATRIX sensor, e.g. DIST500.7-A07.OC is not
part of the delivery and must, therefore, be ordered separately. For an overview for the
selection of the appropriate mounting set see the table on p. 65.
Rev. 1.6
2018-09
• The sensor must be installed horizontally. The maximum permissible deviation
from the horizontal plane should be < ± 5°.
• On doors with special dimensions (installation height < 1.90 m and very, very wide
door areas) the installation must be performed in consultation with iris-GmbH. If
necessary, 2 sensors are installed above the door.
• In the sensor's close-up range of up to 3 cm there must not be any horizontal
vehicle parts such as separators, stationary parts of the mechanical door systems.
