Sensor Selection; Option Dhcp; Fig. 29: Dhcp Option In The Tab „Ethernet - IRIS IRMA MATRIX 2 Installation Manual

48/74 IRMA MATRIX R2 CAN Installation manual
released
8.2.3

Sensor selection

In the sensor selection dialogue the option "UIP-over-UDP" (see Fig. 28) must be active as
otherwise no sensors are shown at all. As a rule, "UIP-over-UDP" is pre-set.
8.2.4

Option DHCP

Fig. 29: DHCP option in the tab „Ethernet"
"DHCP" – The Dynamic Host Configuration Protocol is included in Configuration Tool.
"DHCP" allows the automatic assignment of a network configuration to the sensor(s). For
this purpose, you need to have a DHCP server in the network.
Check the field if you can integrate IRMA MATRIX into the network using an existing DHCP
server.
Rev. 1.6 2018-09
