Check of the installation

First perform a visual check:
• Have all sensors been installed and are they properly attached?
• Have all sensor connecting cables been attached to the rear of the sensors?
• Is the sensor power supply connected?
• Is the IRMA gateway sensor power supply connected?
• Is the IRMA gateway connected to the on-board computer?
• Do the infrared LEDs of the sensors light up when the door is open? Please check
separately for each door!
• Are the infrared LEDs of the sensors out when the door is closed? Please check on each
door individually!
Then the installation is checked using the service software.
10.1

Check with the "IRMA-A21-Windows" service software

The "IRMA-A21-Windows_Release 5" service software is available for downloading on
(https://www.irisgmbh.de/en/technical-documents/service-software/
"IRMA-A21-Windows_Release_5.1.9_User.zip". It in installed on the service PC.
• Connect the laptop to the RS232 service interface of the IRMA gateway. If necessary,
connect it via an RS232-USB converter (accessory), see section 9.1, p. 55.
• Close all vehicle doors.
• Start IRMA-A21-Windows.
Do not read in the "Device list".
Click on the menu item "Communication". Select the communication protocol used:
IBIS, IRMA (UIP
Set the communication options accordingly and check the COM port settings.
Start by pressing "B" and query the system status.
9
UIP- Universal IRMA protocol: proprietary protocol of iris-GmbH for communication between the individual passenger counting
components
Rev. 1.6 2018-09
9
) or J1708.
• All counting zones (doors) must be displayed.
• No counting zone must report defective or sabotaged sensors or sensors "busy
counting".
• All doors must be reported "closed".
) by the name of
