IRIS IRMA MATRIX 2 Installation Manual page 2

2/74 IRMA MATRIX R2 CAN Installation manual
released
Document information
Title of document:
File name:
Revision:
Edition (YYYY-MM):
Type of document:
Status:
Validity
Sensors and connectors covered by this document:
Product
IRMA MATRIX
IRMA MATRIX
IRMA MATRIX
IRMA MATRIX
IRMA MATRIX
Rev. 1.6 2018-09
IRMA MATRIX R2 CAN Installation manual
KDIA_IRMA-MATRIX_R2_Installation-manual-CAN_1.6_en.pdf
1.6
2018-09
Customer documentation (KD)
released
Item type Item
DIST500-A DIST500.7-A07.OC
DIST500-F DIST500.7-F07.OC
sCON-S sCON-S-CAN-20-Kn-x
sCON-S sCON-S-CAN-ETH-23-Kn-x-y
sCON-F-12 sCON-F-12-CC-E
Description
Sensor, surface mount
version
Sensor, flush mount version
Connector (standard) with a
CAN interface for MATRIX
sensors
Connector (standard) with
CAN and Ethernet interfaces
for MATRIX sensors
Connector with one
Ethernet and two CAN
interfaces for MATRIX
sensor DIST500-F (flush-
mount version)
