Fault message
Under voltage P2
Under voltage P3
Under voltage P4
Over voltage P5
Over voltage P6
Overload Failure P1
Overload Failure P2
Overload Failure P3
Overload Failure P4
Overload Failure P5
Overload Failure P6
Brake resistor P1
Brake resistor P4
Brake resistor P3
Brake resistor P4
Brake resistor P5
Brake resistor P6
Temp. Failure P1
Temp. Failure P2
Temp. Failure P3
Temp. Failure P4
Temp. Failure P5
Temp. Failure P6
ATM Failure P1
ATM Failure P2
ATM Failure P3
ATM Failure P4
ATM Failure P5
ATM Failure P6
Flushing
Valve opened oftenly
Circuit Fail. FC1
Circuit Fail. FC2
Circuit Fail. FC3
Circuit Fail. FC4
Circuit Fail. FC5
Circuit Fail. FC6
Ext. Power Operation
Setpoint Reduction
Factory Test
MPO Failure
ASR Shutdown
80 of 88
11 Trouble-shooting
Description
DC link voltage too low, frequency inverter 2
DC link voltage too low, frequency inverter 3
DC link voltage too low, frequency inverter 4
DC link voltage too low, frequency inverter 5
DC link voltage too low, frequency inverter 6
Overload, frequency inverter 1
Overload, frequency inverter 2
Overload, frequency inverter 3
Overload, frequency inverter 4
Overload, frequency inverter 5
Overload, frequency inverter 6
Braking resistor fault, frequency inverter 1
Braking resistor fault, frequency inverter 2
Braking resistor fault, frequency inverter 3
Braking resistor fault, frequency inverter 4
Braking resistor fault, frequency inverter 5
Braking resistor fault, frequency inverter 6
Temperature too high, frequency inverter 1
Temperature too high, frequency inverter 2
Temperature too high, frequency inverter 3
Temperature too high, frequency inverter 4
Temperature too high, frequency inverter 5
Temperature too high, frequency inverter 6
Automatic motor adaptation fault, frequency inverter 1
Automatic motor adaptation fault, frequency inverter 2
Automatic motor adaptation fault, frequency inverter 3
Automatic motor adaptation fault, frequency inverter 4
Automatic motor adaptation fault, frequency inverter 5
Automatic motor adaptation fault, frequency inverter 6
Flushing procedure active
Several flushing procedures carried out
Short circuit/earth fault, frequency inverter 1
Short circuit/earth fault, frequency inverter 2
Short circuit/earth fault, frequency inverter 3
Short circuit/earth fault, frequency inverter 4
Short circuit/earth fault, frequency inverter 5
Short circuit/earth fault, frequency inverter 6
Emergency power mode active; maximum system load
limited
Setpoint reduced due to drop in inlet pressure
No test carried out in factory
Fault in VP mode, synchronous operation
Cancellation of automatic setpoint reduction
BoosterControl Advanced
Type of message
Warning
Alert
✘
-
-
✘
✘
-
-
✘
✘
-
-
✘
✘
-
-
✘
✘
-
✘
-
✘
-
✘
-
✘
-
✘
-
-
✘
✘
-
-
✘
✘
-
-
✘
✘
-
-
✘
✘
-
-
✘
✘
-
-
✘
✘
-
✘
-
✘
-
✘
-
✘
-
✘
-
-
✘
✘
-
-
✘
✘
-
-
✘
✘
-
-
✘
-
✘
-
✘
✘
-
-
✘
