Parameter
Description
Analog output
3-4-1-4-10-5
Configuring the analog output
Auto. Setpoint Redu.
3-4-1-5
Automatic setpoint reduction in case of
inlet pressure drop
ASR function
3-4-1-5-1
Automatic setpoint reduction in case of
inlet pressure drop
Switch on point
3-4-1-5-2
Re-start point
Inlet Set point
3-4-1-5-3
Entering the minimum inlet pressure
setpoint
Switch off point
3-4-1-5-4
Stop point
Proportional const.
3-4-1-5-5
Proportional constant of PID controller
Integral time
3-4-1-5-6
Integral constant of PID controller
Differential time
3-4-1-5-7
Differential constant of PID controller
Switch On time
3-4-1-5-9
Time to pump start
Switch Off time
3-4-1-5-10
Time to pump stop
Discharge
3-4-2
Discharge-side parameterisation
Sensor press. 4 mA
3-4-2-1
Analog measured value at 4 mA,
discharge side
Sensor press. 20 mA
3-4-2-2
Analog measured value at 20 mA,
discharge side
Pumps ON sensor fail
3-4-2-3
Number of pumps started up in the event
of a sensor failure on the discharge side
Max power
3-4-2-4
Limitation of maximum system power (n x
100 %, n = number of pumps)
Max power ext. oper.
3-4-2-5
Limitation of maximum system power for
operation on emergency power
Factory setting
Possible settings
4-20mA
4-20 mA,
0-20 mA
-
-
Off
Off,
On
200
100.. 400
100
0.. 400
90
0.. 100
3
0.. 10
1
0.. 60
0
0.. 99
5
0.. 60
5
0.. 60
-
-
0
-100.. 1000
1000
0.. 9999
0
0.. 3
600
0.. 600
600
0.. 600
min. value
max. value
Read access right Write access right
-
-
Everybody
-
-
Everybody
-
-
Everybody
100
400
Everybody
0
400
Everybody
0
100
Everybody
0
10
Everybody
0
60
Everybody
0
99
Everybody
0
60
Service
0
60
Service
-
-
Everybody
-100
1000
Everybody
0
9999
Everybody
0
3
Everybody
0
600
Everybody
0
600
Everybody
Service
Nobody
Service
Service
Service
Service
Service
Service
Service
Service
Service
Service
Service
Service
Service
Service
Service
