Parameter
Description
Variable freq. drive
3-4-3
Configuring the frequency inverters
Communication
3-4-3-1
Configuring the communication protocol for
the frequency inverter
Proportional const.
3-4-3-2
Proportional constant of PID controller
Integral time
3-4-3-3
Integral constant of PID controller
Differential time
3-4-3-4
Differential constant of PID controller
VFD Ramp-Up
3-4-3-9
Configuring the start ramp for frequency
inverters in seconds
VFD Ramp-Down
3-4-3-10
Configuring the stop ramp for frequency
inverters in seconds
VFD min. frequency
3-4-3-11
Configuring the minimum frequency for
frequency inverters in Hz
VFD max. frequency
3-4-3-12
Configuring the maximum frequency for
frequency inverters in Hz
P nominal of VFD
3-4-3-13
Nominal power of frequency inverters
U nominal of VFD
3-4-3-14
Nominal voltage of frequency inverters
F nominal of VFD
3-4-3-15
Nominal frequency of frequency inverters
I nominal of VFD
3-4-3-16
Nominal amperage of frequency inverters
RPM nominal of VFD
3-4-3-17
Nominal speed of frequency inverters
Motor Speed Unit
3-4-3-20
Motor speed unit
Digital I/P 33 func.
3-4-3-21
Selecting the digital input
Digital I/P 29 func.
3-4-3-22
Selecting the digital input
Factory setting
Possible settings
-
-
None
None,
Analog 4-20 mA,
Analog 0-20 mA,
PumpDrive,
Danfoss VLT 2800,
Danfoss MicroDrive,
Danfoss AquaDrive
3
0.. 100
1
0.. 60
0
0.. 99,99
3
0,1.. 999
3
0,1.. 999
30
0.. 50
50
30.. 140
1500
0.. 100000
400
0.. 500
50
50.. 50
4
0.. 450
2880
0.. 10000
U/min
Rpm,
Hz
No function
No function,
Coasting stop inv.
No function
No function,
Jog function,
Jog function
min. value
max. value
Read access right Write access right
-
-
Everybody
-
-
Everybody
0
100
Everybody
0
60
Everybody
0
99,99
Everybody
0,1
999
Everybody
0,1
999
Everybody
0
50
Everybody
30
140
Everybody
0
100000
Everybody
0
500
Everybody
50
50
Everybody
0
450
Everybody
0
10000
Everybody
-
-
Everybody
-
-
Everybody
-
-
Everybody
Nobody
Service
Service
Service
Service
Service
Service
Service
Service
Service
Service
Service
Service
Service
Service
Service
Service
