Table 23: Status information 1
Parameter Description
1-1-1 Actual system pressure measured by BoosterControl
Advanced
1-1-2 Display system load (all pumps in operation)
1-1-3 RDP switch (dry running protection)
1-1-4 Inlet pressure
1-1-5 Level in inlet tank
1-1-6 Level in inlet tank
1-1-7 If temperature sensor available:
Display of measured ambient temperature
1-1-8 Display of status of digital inputs (only from service
access level)
1-1-9 Position of supply valve
Table 24: Status information 2
Parameter Description
1-2-1 Operating status of a pump
1-2-2 Pump load
1-2-3 Motor protection
1-2-4 Pump operating hours
1-2-5 Number of pump starts per pump:
30 of 88
6 Operation

6.4.7 Displaying status information

Measured values are updated every second. Measurements are taken more rapidly,
however.
Displaying general information
General information on operation is displayed at the top menu level.
Select parameter 1-1.
The following information can be displayed:
Displaying information on pumps connected
Select parameter 1-2.
The following information can be displayed:
Displaying statistics
Select parameter 1-3.
The following information can be displayed:
Parameter description
Table 25: Status information 3
Parameter Description
1-3-1 Operating hours of system (hours:minutes)
1-3-2 Time to next service
1-3-3 Actual min. runtime of pump
BoosterControl Advanced
Possible values
0 ... 10000 kPa
0 ... 100 %
Available
Not available
-100 ... 10000 kPa
0 ... 100 %
0 ... 9999 cm
0 ... 100 °C
0 enabled
1 disabled
Open
Closed
Possible values
Automatic
Manual ON (10 s fixed)
Manual OFF
0 ... 100 %
0 not tripped
1 tripped
Days Hours: Minutes
Pump: Starts
