11 Trouble-shooting
Description
External fire alert command for starting all pumps active
Fault, frequency inverter
Fault, pressure-side pressure sensor
Fault, suction-side pressure sensor
Fault, several frequency inverters
Leak detected
EEPROM data not saved due to hardware problems
Pump 1 switched off
(independent of automatic mode)
Pump 2 switched off
(independent of automatic mode)
Pump 3 switched off
(independent of automatic mode)
Pump 4 switched off
(independent of automatic mode)
Pump 5 switched off
(independent of automatic mode)
Pump 6 switched off
(independent of automatic mode)
Pump 1 in manual mode
(independent of automatic mode)
Pump 2 in manual mode
(independent of automatic mode)
Pump 3 in manual mode
(independent of automatic mode)
Pump 4 in manual mode
(independent of automatic mode)
Pump 5 in manual mode
(independent of automatic mode)
Pump 6 in manual mode
(independent of automatic mode)
Several pumps switched off (independent of automatic
mode)
Internal fault, frequency inverter 1
Internal fault, frequency inverter 2
Internal fault, frequency inverter 3
Internal fault, frequency inverter 4
Internal fault, frequency inverter 5
Internal fault, frequency inverter 6
Power supply fault, frequency inverter 1
Power supply fault, frequency inverter 2
Power supply fault, frequency inverter 3
Power supply fault, frequency inverter 4
Power supply fault, frequency inverter 5
Power supply fault, frequency inverter 6
DC link voltage too high, frequency inverter 1
DC link voltage too high, frequency inverter 2
DC link voltage too high, frequency inverter 3
DC link voltage too high, frequency inverter 4
DC link voltage too high, frequency inverter 5
DC link voltage too high, frequency inverter 6
DC link voltage too low, frequency inverter 1
BoosterControl Advanced
Type of message
Warning
Alert
-
✘
-
✘
-
✘
-
✘
-
✘
-
✘
-
✘
-
✘
✘
-
✘
-
✘
-
✘
-
✘
-
-
✘
-
✘
-
✘
✘
-
✘
-
✘
-
✘
-
✘
-
✘
-
✘
-
✘
-
✘
-
✘
-
-
✘
✘
-
-
✘
✘
-
-
✘
✘
-
-
✘
✘
-
-
✘
✘
-
-
✘
✘
-
✘
-
