5 Installation at Site

5 Installation at Site

5.1 Safety regulations

DANGER
Incorrect installation
Danger to life!
▷ Install BoosterControl Advanced in a flood-proof location.
▷ Never use BoosterControl Advanced in potentially explosive atmospheres.

5.2 Checking ambient conditions

1. Check and safeguard ambient conditions. (ð Section 8.1, Page 34)
2. Contact the manufacturer if the device is to be used under ambient conditions
other than indicated.
3. Verify that the place of installation meets the following requirements:
- Sufficient space for installation/removal and proper ventilation
- No direct sunlight
- Protected against freezing
- Flood-proof

5.3 Installing BoosterControl Advanced

Install BoosterControl Advanced while referring to the outline drawing.

5.4 Electrical connection

DANGER
Incorrect electrical installation
Danger of death from electric shock!
▷ Any work on the electrical system shall be undertaken by a trained electrician
only (DIN VDE 0105 - Part 1/07.83).
▷ Before commencing any work on the electrical installations, de-energise the
system and make sure it cannot be re-started unintentionally. Ensure staff
1)
safety by PELV :
▷ Only motor protection devices with safe isolation to EN 50178 (VDE 0160) may
be connected directly.
CAUTION
Improper electrical connection
Damage to property
▷ All connections shall be made in accordance with the technical specifications
issued by the local energy supply companies.
▷ Check the type of current and voltage of the mains.

5.4.1 Electrical connections

All electrical connections of BoosterControl Advanced to the power relays or
contactors must always have circuit protection.
If more than two apparatuses are controlled in a control cabinet, always provide for
a separate control voltage supply in the control cabinet (as per EN 60204).
BoosterControl Advanced
