Parameter Description
3-4-3-5 Enable/disable flow detection and accuracy of flow
detection
3-4-3-5-1 Activate flow detection: Flow bandwidth
3-4-3-5-2 Interval for flow measurement ("0" deactivates the
function)
3-4-3-5-3 Step height for detecting the zero flow
3-4-3-4-4 Define maximum pump load ("0" deactivates the
function)
3-5-1 System pressure setpoint
3-5-3 Pressure bandwidth: range above and below the
setpoint where pumps are not stopped or started.
Permissible symmetrical deviation from the setpoint.
3-5-5 Maximum setpoint
3-6-2 Limit for minimum runtime of pump
3-6-4 Maximum pump runtime. After this period,
BoosterControl Advanced starts the pump with the
least operating hours
3-6-5 When one pump is running: start delay of each
pump that cuts in
3-6-6 When more than one pump is running: stop delay of
the pumps
3-12 Fault behaviour: specifies how the control system
should behave in the event of a fault
7)
x depends on the maximum value of the pressure sensor used.
40 of 88
8 Commissioning/Start-up/Shutdown
BoosterControl Advanced
Possible values
0 deactivated
1.. Measuring interval = 20 s
Permissible load change = ±2 %
...9 Measuring interval = 4 s
Permissible load change = ±18 %
0-0,5 bar
0-60 s
1..100%
0.100%
7)
0 ... x kPa
0 ... 1000 kPa
7)
0 ... x kPa
0 ... 999 s
0 ... 356400 s
0 ... 999 s
0 ... 999 s
Cascade
Deactivation
