Parameter
Description
Threshold
3-4-1-4-8
1 or 2 extra signalling relay contacts for
switching thresholds
Threshold 1 ON
3-4-1-4-8-1
Inlet tank level for relay 1 energised in
percent
Threshold 1 OFF
3-4-1-4-8-2
Inlet tank level for relay 1 de-energised in
percent
Threshold 2 ON
3-4-1-4-8-3
Inlet tank level for relay 2 energised in
percent
Threshold 2 OFF
3-4-1-4-8-4
Inlet tank level for relay 2 de-energised in
percent
Supply valve ON/OFF
3-4-1-4-9
Position of inflow gate valve for filling inlet
tank
Level 1 open
3-4-1-4-9-1
Level for opening gate valve to start filling
inlet tank
Level 1 closed
3-4-1-4-9-2
Level for closing gate valve to stop filling
inlet tank
Level 1A open
3-4-1-4-9-3
Second level (timer-based) for opening
gate valve to start filling
Level 1A closed
3-4-1-4-9-4
Second level (timer-based) for closing gate
valve to stop filling
Supply valve prop.
3-4-1-4-10
Use of a proportional valve to fill inlet tank
Level setpoint 1
3-4-1-4-10-1
Level in inlet tank at which valve is
completely closed
Level setpoint 1A
3-4-1-4-10-2
Second level (timer-based) in inlet tank at
which valve is completely closed
Hysteresis
3-4-1-4-10-3
Setting the hysteresis for fully open valve
Sample time
3-4-1-4-10-4
Measurement cycle for measuring to
control proportional valve
Factory setting
Possible settings
-
-
50
0...199
50
0...199
40
0...199
40
0...199
-
-
70
0.. 99
90
0.. 99
40
0.. 99
60
0.. 99
-
-
80
0.. 99
40
0.. 99
15
0.. 99
10
0.. 99
min. value
max. value
Read access right Write access right
-
-
Everybody
0
199
Everybody
0
199
Everybody
0
199
Everybody
0
199
Everybody
-
-
Everybody
0
99
Everybody
0
99
Everybody
0
99
Everybody
0
99
Everybody
-
-
Everybody
0
99
Everybody
0
99
Everybody
0
99
Everybody
0
99
Everybody
Service
Service
Service
Service
Service
Nobody
Service
Service
Service
Service
Nobody
Service
Service
Service
Service
