Parameter Description
WSD pulses tank 3
1-1-16
Water flow detection, number of fills in
tank 3
Pumps
1-2
Pump-relevant status information
Operating mode
1-2-1
Setting the operating mode for each
individual pump
Pump number
1-2-1.1.1
Entering the pump number for which the
operating mode is configured
Operating mode
1-2-1.2.1
Displaying the operating status of the
pump
Pump load
1-2-2
Displaying the pump load
Thermal fail. flags
1-2-3
Bit-based display of status of all thermal
fault inputs
Running hours pump
1-2-4
Displaying the operating hours per pump
Number of pumpstarts
1-2-5
Displaying the number of starts per pump
Time and statistics
1-3
Operating times and statistics
Act runtime Op hours
1-3-1
Operating hours of the system
Time to service
1-3-2
Time to next service interval
Act Minimum Runtime
1-3-3
Current minimum pump runtime in
seconds
Diagnosis
2
Monitoring and diagnosis
General
2-1
General monitoring functions
Active Messages
2-1-1
Current messages for all available
warnings/alerts
History
2-1-2
History of all warnings/alerts
Acknowledge All
2-1-3
All messages are acknowledged
Factory setting Possible settings
0 -
- -
- -
1 1.. 3
1 Automatic,
Manual On (10 s),
Manual Off
- -
- Not tripped
Tripped
- -
- -
- -
0 -
0 -
- -
- -
- -
- -
- -
- -
min. value max. value Read access right Write access right
- - Everybody
- - Everybody
- - Everybody
1 3 Everybody
- - Everybody
- - Everybody
- - Service
- - Everybody
- - Customer
- - Everybody
- - Everybody
- - Everybody
- - Everybody
- - Everybody
- - Everybody
- - Everybody
- - Everybody
- - Everybody
Nobody
Nobody
Everybody
Everybody
Everybody
Nobody
Nobody
Nobody
Nobody
Nobody
Nobody
Nobody
Nobody
Nobody
Nobody
Customer
Nobody
Everybody
